SERVICE INFORMATION
TILLER HANDLE
OTHERS
Material Location Remarks
Use marine grease
(water resistant urea based
grease)
Steering friction rod seating area
Tiller handle shift frame side and upper surface
Throttle rod sliding surface
Tiller handle shift arm pin spring outer surface
Shift arm pin outer surface
Shift gear bushing outer surface
Shift gear teeth and roller contact area and steel ball
contact area
Throttle cable pivot sliding surface
Throttle arm fulcrum and pin outer surface
Shift lever O-ring whole surface
Shift lever bushing outer surface
Shift lever sliding surface
Shift lever stopper sliding surface
Tiller handle grip pipe installation part
Throttle friction pad circumference
Throttle cable pin whole surface
Grip pipe inner wall
Steering handle bushing inner surface
Steering bracket washer (12 mm large) whole surface
Steering bracket wave washer whole surface
Steering bracket and tiller handle pivot area
Liquid sealant
(Threebond® 1216E or
equivalent)
Tiller handle housing See page 19-35
Material Location Remarks
Use marine grease
(water resistant urea based
grease)
Extension case grommet water tube insertion part
Water mouth nut seat contact area
Flash valve cover O-ring
Liquid sealant
(Threebond® 5222L or
equivalent)
Extension case oil case side seal surface See page 16-12
Loctite® PRISM 403 Water joint cap nut seating surface
Loctite® 460 Engine cover seal See page 6-3
