TOHATSU BFT75A - Page 312

10-5
dummyheaddummyhead
OTHER ELECTRICAL
Insert a screwdriver or equivalent tool [1] into the
locking lug [2] on the fuse box [3] and unlock.
With the lock unlocked, pull the fuse box toward you.
Remove the fuse box from the fuse box bracket [4].
Remove the power trim/tilt switch 3P connector [1] and
the two harness band clips [2] from the fuse box bracket
[3].
Remove the two bolts [4] and fuse box bracket.
Installation is in the reverse order of removal.
Route the wire harness properly (page 2-18).
[3]
[2]
[4]
[1]
[1]
[4]
[2]
[3]
[3]
[4]
[1]
[2]
