14-23
dummyheaddummyhead
CYLINDER HEAD
Check whether the fuel pump lifter [1] is in contact with
the camshaft [2]. If it is, push the fuel pump lifter in
toward the cylinder head side.
Remove the cam pulser plate bolt [1] from the camshaft
[2], and remove the cam pulser plate [3].
Remove the camshaft from the oil pump side of the
cylinder head assembly.
Remove the fuel pump lifter [1] from the cylinder head
assembly.
[2]
[1]
[1]
[1]
[3]
[2]
[1]
