CYLINDER BLOCK
Remove the ten bolts [1] from the crankcase.
Loosen the ten bolt/washers [1] in the numbered order
shown in two or three steps.
Remove the ten bolt/washers from the crankcase.
Insert a screwdriver into the recesses in the crankcase
and separate the crankcase a little at a time.
• Take care not to damage the crankcase and cylinder
block mating surfaces.
