2-30
dummyheaddummyhead
SERVICE INFORMATION
MAIN HARNESS
HARNESS
STRAP (30 mm)
CMP SENSOR
CMP SENSOR
3P CONNECTOR
HARNESS BAND
CLIP
HARNESS BAND CLIP
(BF90D/BF100A only)
VTEC SOLENOID 1P
CONNECTOR
(BF90D/BF100A only)
HARNESS CLIP
VTEC SOLENOID
(BF90D/BF100A only)
MAIN HARNESS
