CONTROLS
COMPONENTS DRAWING
HARNESS BAND
CLIP
6P
CONNECTOR
STARTER CABLE
SHIFT LINK PIN
14P
CONNECTOR
BOLT
(6 x 16 mm) (2)
REMOTE CONTROL
CABLE COVER
SHIFT PIVOT/
LOCK PLATE
THROTTLE ARM
LINK PIN
FUEL TUBE A
REMOTE CONTROL
CABLE PLATE
UNDER CASE
GROMMET BAND
REMOTE CONTROL
CABLE GROMMET
REMOTE CONTROL
CABLE (SHIFT SIDE)
REMOTE CONTROL CABLE
(THROTTLE SIDE)
