SERVICE INFORMATION
Set into the alternator
cover clamp.
BREATHER PIPE
FUEL TUBE CLAMP B
ALTERNATOR
COVER
Set into the alternator
cover clamps.
BREATHER TUBE C
ALTERNATOR
COVER CLAMP
BREATHER
TUBE A
FUEL TUBE
JOINT
BREATHER
TUBE B
Set into the alternator
cover clamps.
BREATHER PIPE
ALTERNATOR
COVER
SILENCER CASE
PAINT MARK
• Set into the alternator cover
clamps.
• Insert into the silencer case until
the paint mark is not visible.
BREATHER TUBE C
ALTERNATOR
COVER CLAMPS
ALTERNATOR
COVER CLAMP
ALTERNATOR
COVER CLAMPS
