SELF-DIAGNOSTIC MODE
2 - 134
2.6.5 Counter
In this equipment, a toner image is formed on the transfer belt prior to a paper feeding.
When the feeding retry occurs and the transport timing is delayed, the toner image on the
transfer belt is cleaned off without the 2nd transfer since the paper cannot be reached for the 2nd
transfer process.
After that, the toner image formation is retried while the paper is waited.
In this case, the toner for this image formation is consumed wastefully since the toner image on
the transfer belt is already cleaned off, even though the printing is normally completed.
Therefore, note that the excessive toner will be consumed consequently when the upper limit
value of feeding retry counter is set larger or set as “0” (no limit).
The toner is also consumed wastefully when the paper misfeeding occurs. Replace the roller at
earlier timing if the paper misfeedings have occurred frequently.
Setting mode (08)
Code
Classific
ation
Items
Functi
on
Default
<Accept
able
value>
RAM Contents
Proce
dure
251 Maintena
nce
Setting value of PM
counter / K
ALL
(black)
Refer to
content
<8 digits>
M Sets the threshold for
displaying a message
for PM timing.
0: Not displayed
<Default>
e-STUDIO5520C
: 225,000
e-STUDIO6520C
: 250,000
e-STUDIO6530C
: 275,000
1
252 Maintena
nce
Current value of PM
counter Display/0 clearing /
K
ALL
(black)
0
<8 digits>
M Counts up when the
registration sensor is
ON.
08-1150-0
1
344 Counter Count setting of tab paper
(PM)
ALL 1
<0-1>
M 0: Counted as 1
1: Counted as 2
1
346 Counter Count setting of large-
sized paper (PM)
ALL 1
<0-1>
M 0: Counted as 1
1: Counted as 2
1
347 Counter Definition setting of large
sized paper (PM)
ALL 1
<0-1>
M 0: A3/LD
1: A3/LD/B4/LG/
FOLIO/COMP
1
348 Counter Count setting of thick
paper (PM)
ALL 1
<0-1>
M 0: Counted as 1
1: Counted as 2
1
349 Counter Count setting of OHP film
(PM)
ALL 1
<0-1>
M 0: Counted as 1
1: Counted as 2
1
352 Counter Count setting of large-
sized paper (Fee charging
system counter)
ALL JPN: 0
OTHER:
1
<0-2>
M 0: Counted as 1
1: Counted as 2
2: Counted as 1
(Mechanical counter
is double counter)
1
353 Counter Definition setting of large
sized paper (Fee charging
system counter)
ALL 0
<0-1>
M0:A3/LD
1: A3/LD/B4/LG/
FOLIO/COMP
1
375
Mai
ntena
nce
Setting value of PM time
counter display/0 clearing /
K
ALL
(black)
285,000
<8 digits>
M Sets the threshold for
displaying a message
for PM timing.
0: Not displayed
1
376 Maintena
nce
Current value of PM time
counter / K
ALL
(black)
0
<8 digits>
M Counts the drum driving
time.
08-1150-3
