1. Precautions for Transporting Equipment Once Unpacked
1 General Description
It is recommended to follow the procedure below when you transport equipment that has already
been unpacked but has not been packed again. Note that the following procedure cannot guarantee
the operation of the transported equipment.
• Keep packing material removed at unpacking to reuse it in steps (2) and (3) above.
• Use a service jig PLATE-TONER-SEAL-4P (6LH035950, 4 pieces in 1 set) as sealing material
to be used in step (4) above.
• Do not install the accessories shown below when unpacking the equipment.
Item Content
(1) Gasket in Reversing Automatic
Document Feeder (RADF)
Check that gaskets are not installed in the RADF.
(If they are installed, remove them.)
(2) Scanning section Fix the scanning section.
(3) Drum Install a drum protection sheet.
(4) Toner Install sealing material on the toner supply opening of each
toner cartridge.
To Next Page
