e-STUDIO5520C/6520C/6530C © 2008-2011 TOSHIBA TEC CORPORATION All rights reserved
POWER SUPPLY UNIT
9 - 4
Output voltage by the type of connector
Main switch line
Cover switch line
AC line
Connector Destination Voltage
J898 For the SYS board (via relay harness) +5.1VA, +5.1VB, +5.1VS, +12VA, +12VB
CN403 For the IMG board +5.1VB
CN404 For the LGC board, LCF (via LGC board) +5.1VB, +12VB
CN405 For the LGC board +5.1VB
CN406 For the Finisher +5.1VB
CN407 For the SLG board, RADF +5.1V, +12VB
Connector Destination Voltage
CN405 For the LGC board, LCF (via LGC board),
high-voltage transformer (via LGC board)
+5.1VD, +24VD1, +24VD2, +24VD3
CN406 For the Finisher +24VD4
CN407 For the SLG, RADF +24VD5
Connector Destination Voltage
CN401 AC input -
CN408 Heater lamp Lamp output
CN425 Output from the LIVE of AC inlet to the
reactor
AC input (cover switch line)
CN426 Input from the reactor to the LIVE AC input (cover switch line)
