POWER SUPPLY UNIT
9 - 6
+24VD2 LGC board Transfer belt motor M13 F202:
8 A (Semi time-lag)
Sub-hopper toner motor-K M19
Sub-hopper toner motor-C M20
Sub-hopper toner motor-M M21
Sub-hopper toner motor-Y M22
Needle electrode cleaner motor-K M23
Needle electrode cleaner motor-C M24
Needle electrode cleaner motor-M M25
Needle electrode cleaner motor-Y M26
Waste toner transport motor M33
Polygonal motor M34
Mirror motor-M M35
Mirror motor-C M36
Mirror motor-K M37
Shutter motor M38
Auto-toner sensor-K S26
Auto-toner sensor-C S27
Auto-toner sensor-M S28
Auto-toner sensor-Y S29
Drum surface potential (V0) sensor-K S34
Drum surface potential (V0) sensor-C S35
Drum surface potential (V0) sensor-M S36
Drum surface potential (V0) sensor-Y S37
Image quality shutter solenoid SOL3
V0 sensor shutter solenoid-K SOL4
V0 sensor shutter solenoid-C SOL5
V0 sensor shutter solenoid-M SOL6
V0 sensor shutter solenoid-Y SOL7
IH board cooling fan-1 F8
IH board cooling fan-2 F9
EPU cooling fan F14
Toner cartridge heat insulation fan F21
Laser optical unit cooling fan (Front) F22
Ozone suctioning fan F24
Scattered toner suctioning fan F25
Toner cooling exhaust fan F31
High-voltage transformer-1 HVT1
High-voltage transformer-2 HVT2
PFC board Tray-up motor-1 M44
3rd drawer transport clutch CLT4
3rd drawer feed clutch CLT5
4th drawer transport clutch CLT6
4th drawer feed clutch CLT7
Bridge unit cooling fan (front) F6
Bridge unit cooling fan (rear) F7
Stopper opening/closing solenoid
(front)
SOL10
Stopper opening/closing solenoid
(rear)
SOL11
Voltage Board/Unit Part Fuse type
