5-6 Expansion Modules
Input/Output Modules
Trio Motion Technology
The CAN 16-I/O modules are powered from the network. The 24 volts supply
for the network must be externally connected. The Motion Coordinator does
NOT provide the network power. In many installations the power supply for
the Motion Coordinator will also provide the network power.
Note:
It is recommended that you use a separate power supply from that used to
power the I/O to power the network as switching noise from the I/O
devices may be carried into the network.
DIP Switch Settings
Alternative connection protocols
The DIP switches can be set up to allow for different protocols to be used,
enabling the Trio I/O module to be used with other manufacturers devices. At
present the only other protocol supported is that utilised by LENZE drives.
The DIP switch marked “PR” selects the protocol to be used. Switched right it
selects the TRIO protocol, switched left it selects the module to act as a
LENZE drive expansion I/O.
Address: Start: End:
0
16 31
1
32 47
2
48 63
3
64 79
4
80 95
5
96 111
6
112 127
7
128 143
8
144 159
9
160 175
10
176 191
11
192 207
12
208 223
13
224 239
14
240 255
15
256 271
