u-blox ZED-F9P User Manual

u-blox ZED-F9P Interface Description - Manual
Advance Information
5.12.8.3 UBX-MGA-QZSS-HEALTH
Message
UBX-MGA-QZSS-HEALTH
Description
QZSS Health Assistance
Firmware
Supported on:
• u-blox 9 with protocol version 27
Type
Input
Comment
This message allows the delivery of QZSS health assistance to a receiver. See the description
of AssistNow Online for details.
Header Class ID Length (Bytes) Payload Checksum
Message Structure
0xB5 0x62 0x13 0x05 12
see below
CK_A CK_B
Payload Contents:
Byte Offset Number
Format
Scaling Name Unit Description
0 U1 - type - Message type (0x04 for this type)
1 U1 - version - Message version (0x00 for this version)
2 U1[2] - reserved1 - Reserved
4 U1[5] - healthCode - Each byte represents a QZSS SV (1-5). The 6
LSBs of each byte contains the 6 bit health code
from subframes 4/5, data ID = 3, SV ID = 51
9 U1[3] - reserved2 - Reserved
UBX-18010854 - R04 Advance Information Page 126 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
