Timepulse Configuration (CFG-TP-*) Configuration Defaults continued
Configuration Item Key ID Type Scale Unit Default Value
CFG-TP-PERIOD_LOCK_TP1 0x40050003 U4 0.
00000
1
s 1000000
CFG-TP-FREQ_TP1 0x40050024 U4 - Hz 1
CFG-TP-FREQ_LOCK_TP1 0x40050025 U4 - Hz 1
CFG-TP-LEN_TP1 0x40050004 U4 0.
00000
1
s 0
CFG-TP-LEN_LOCK_TP1 0x40050005 U4 0.
00000
1
s 100000
CFG-TP-DUTY_TP1 0x5005002a R8 - % 0
CFG-TP-DUTY_LOCK_TP1 0x5005002b R8 - % 10
CFG-TP-USER_DELAY_TP1 0x40050006 I4 0.
00000
0001
s 0
CFG-TP-TP1_ENA 0x10050007 L - - 1 (true)
CFG-TP-SYNC_GNSS_TP1 0x10050008 L - - 1 (true)
CFG-TP-USE_LOCKED_TP1 0x10050009 L - - 1 (true)
CFG-TP-ALIGN_TO_TOW_TP1 0x1005000a L - - 1 (true)
CFG-TP-POL_TP1 0x1005000b L - - 1 (true)
CFG-TP-TIMEGRID_TP1 0x2005000c E1 - - 0 (UTC)
Tx-Ready Configuration (CFG-TXREADY-*) Configuration Defaults
Configuration Item Key ID Type Scale Unit Default Value
CFG-TXREADY-ENABLED 0x10a20001 L - - 0 (false)
CFG-TXREADY-POLARITY 0x10a20002 L - - 0 (false)
CFG-TXREADY-PIN 0x20a20003 U1 - - 0
CFG-TXREADY-THRESHOLD 0x30a20004 U2 - - 0
CFG-TXREADY-INTERFACE 0x20a20005 E1 - - 0 (I2C)
Configuration of the UART1 Interface (CFG-UART1-*) Configuration Defaults
Configuration Item Key ID Type Scale Unit Default Value
CFG-UART1-BAUDRATE 0x40520001 U4 - - 38400
CFG-UART1-STOPBITS 0x20520002 E1 - - 1 (ONE)
CFG-UART1-DATABITS 0x20520003 E1 - - 0 (EIGHT)
CFG-UART1-PARITY 0x20520004 E1 - - 0 (NONE)
CFG-UART1-ENABLED 0x10520005 L - - 1 (true)
Input Protocol Configuration of the UART1 Interface (CFG-UART1INPROT-*) Configuration Defaults
Configuration Item Key ID Type Scale Unit Default Value
CFG-UART1INPROT-UBX 0x10730001 L - - 1 (true)
CFG-UART1INPROT-NMEA 0x10730002 L - - 1 (true)
CFG-UART1INPROT-RTCM3X 0x10730004 L - - 1 (true)
UBX-18010854 - R04 Advance Information Page 254 of 259
