CFG-PRT continued
Byte Offset Number
Format
Scaling Name Unit Description
4 X4 - mode - DDC Mode Flags (see graphic below)
8 U1[4] - reserved2 - Reserved
12 X2 - inProtoMask - A mask describing which input protocols are
active.
Each bit of this mask is used for a protocol.
Through that, multiple protocols can be defined
on a single port. (see graphic below)
14 X2 - outProtoMask - A mask describing which output protocols are
active.
Each bit of this mask is used for a protocol.
Through that, multiple protocols can be defined
on a single port. (see graphic below)
16 X2 - flags - Flags bit mask (see graphic below)
18 U1[2] - reserved3 - Reserved
Bitfield txReady
This graphic explains the bits of txReady
Name Description
en
Enable TX ready feature for this port
pol
Polarity
0 High-active
1 Low-active
pin
PIO to be used (must not be in use already by another function)
thres
Threshold
The given threshold is multiplied by 8 bytes.
The TX ready PIN goes active after >= thres*8 bytes are pending for the port and going inactive after the last
pending bytes have been written to hardware (0-4 bytes before end of stream).
0x000 no threshold
0x001 8byte
0x002 16byte
...
0x1FE 4080byte
0x1FF 4088byte
UBX-18010854 - R04 Advance Information Page 72 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
