1-12 TM-500 User’s Guide
Installing 2D & 3D Vision Systems D292144.4.fm
Installing 2D & 3D Vision Systems
Vision installation may only be performed by qualified V-TEK Service personnel.
Keyence 2D Vision
(2D over Tape shown above.)
UltraVim 2D Vision
(2D over Tape shown above.)
Upward 2D Inspection
(Perimeter Inspection shown above.)
UltraVim 3D Vision
(UX Model shown above.)
