Commands Diagnostics Section
©Vertical Express 3-20 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
SCCT
Set Car Call Top - This command sets the top landing car call. To set, type SCCT and press Enter.
• If the top landing has a front opening, the front car call will be set.
• If the top landing does not have a front opening, the rear car call will be set.
See also: SCC, SCCB, SDC, SRC, SRD, SRU, SUC
SDC
Set Down Call - This command simulates a group down hall call assignment to this car at nth landing; Only this
car will respond to this call.
See also: SCC, SCCB, SCCT, SRC, SRD, SRU, SUC
SFL
Secure Floor Lockout - This command locks out access to a floor from its car call button (Fire Service will over-
ride).
Sets manual lockout or lockout override for front car call(s). A lockout will lock out a car call until an override is
activated, and a lockout override will unlock a floor until it is removed.
SFLR
Secure Floor Lockout Rear - This command locks out access to a floor from its car call button (Fire Service will
override).
Sets manual lockout or lockout override for rear car call(s). A lockout will lock out a car call until an override is
activated, and a lockout override will unlock a floor until it is removed.
SHL
Secure Floor Lock Command for Hall Calls - This command locks out access to a hall button on all cars in a
group.
SPC Safety Processor Configure - This command requires JP2 on the IOF Card to be across pins 1-2.
SRC Set Rear Car Call - This command registers a rear car call from the UIT.
SRD
Set Rear Down Call - This command sets the nth landing rear down car call.
See also: SCC, SCCB, SCCT, SDC, SRD, SRU, SUC.
SRU
Set Rear Up Call - This command sets the nth landing rear up car call.
See also: SCC, SCCB, SCCT, SDC, SRD, SRU, SUC.
SSI
Special Security Initialization - This command restores the Job EPROM defaults.
Note: Only for jobs with special security.
STU
Selector Setup Command - This command disregards the door limit and door zone inputs.
Verify that the car door is closed before running the car from this
command; equipment damage could result.
STUA
Setup Automatic Command - This command performs an automatic hoistway learn; the car must be on Door
Disconnect, and then the car will lower to the bottom DL and scan the hoistway.
SUC
Set Up Call - This command simulates a Group Up Hall Call assignment to this car at nth landing.
Note: Only this car will respond to this call.
See also: SCC, SDC, SRD, SRU, SUC.
TECC Teach CAN Configuration - This command configures all online nodes.
TECCR This command erases the TECC configuration information on all CAN nodes communicating on Channels 2 & 3.
TMP This command displays the current ambient controller temperature.
UDLS This command saves all the controller files to the USB stick drive folder “/tke/backup/xxnnnn.”
UDLR This command copies files from the “/tke/backup/xxnnnn” folder to the “/tke/update” folder.
UFWCNC This command displays the CAN Node - Car Channel (CH:2).
UFWCNH This command displays the CAN Node - Hall Channel (CH:3).
UFWSLF This command updates the SEL from a USB flash drive.
UFWSPF This command updates the Safety Processor software from a USB flash drive.
VER
Version - This command displays the version/revision of Car Generic Software, Safety Processor, NTSD
Processor, OS, and FPGAs, as well as the job number of the controller for which the software was designed.
WJR This command displays Jack resync activity.
WRT
Write Parameters - This command saves working values in RAM memory to the EEPROM (which protects the
working values in the event the controller's power is lost). Note: On power-up, or if terminal is disconnected, the
working values are read from EEPROM into RAM memory.
WRTG This command writes group adjustments to all controllers connected to the group.
Name (cont.) Definition (cont.)
