Installation Section Car Top Wiring
Car Top Wiring
• Slotted end caps and cover plates are shipped from Manufacturing in a wiring
package.
• In all steps, leave any excess wire in the header.
• Unless stated otherwise, all of the following steps are for all jobs.
1. Insert the end of the selector harness through the end of the header and into the
main swing return. Connect flex conduit to the car header end cap, or where the
selector harness enters the car; leave wires disconnected in the swing return.
2. Connect the front door operator harness to the slotted cover plate, and pull the
MTA connectors through the header and into the main swing return; leave dis-
connected in the swing return.
3. On jobs with selective doors, wire the rear door operator harness as follows:
a. Begin in the rear header nearest the door operator, and connect the flex con-
duit from the rear door operator harness to the slotted cover plate.
b. Pull the rear door operator harness out through the rear header cover plate
to the 2
1
/
2
" wireway that runs along the side of the car top.
c. In the second hole of the 2
1
/
2
" wireway, attach flex conduit onto the harness.
d. In the opposite end of the 2
1
/
2
" wireway cover, start at the second hole and
attach the next section of flex conduit to the cover plate of the front header.
e. Route the harness cable through the front header and pull the connectors
into the main swing return; leave disconnected in the swing return.
4. Connect the wires from the door protective device to the door operator.
5. Install conduit, and pull lights and fan wiring to main swing return terminal strip.
6. Pull the front auxiliary swing return harness through the header and into the
main swing return.
Required Material
– Door operator harness - front & rear, as required
– Auxiliary swing return harness, as required – Fan and lights harness
– 2
1
/
2
" wireway - rear doors only –
1
/
2
" flex conduit and fittings
– Slotted end cap(s) – Slotted cover plates
