DIAGNOSTICS
Vertical Express Product Manual 3-29 88500 v.1.0
Diagnostics Section Inputs and Outputs
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
No Known Application Rule I/O
These I/O exist in the software but currently have no known application rules.
TEMPOK Ambient Controller Temperature OK
TFE Transfer Floor Operation Enable
THLK Total Hall Call Lockout
TLOJ Total Lockout Jewel
TMPI Tamper Indicator
TMPIR Tamper Indicator Reset
U1-U15 Hall Call - Up - Combination I/O
UI1-UI63 Hall Call - Up - Input
UJ1-UJ64 Up Hall Call Lockout Jewel Outputs
UL1-UL63 Hall Call - Up - Lockout
ULO1-ULO63 Security Up Hall Call Override Inputs
ULOR1-ULOR63 Hall Call - Up - Rear - Lockout Override
ULR1-ULR63 Hall Call - Up - Rear - Lockout
UO1-UO63 Hall Call - Up - Output
UPK Up Peak Operation
UPKJ Up Peak Jewel
UR1-UR63 Hall Call - Up - Rear - Combination I/O
URI1-URI63 Hall Call - Up - Rear - Input
URJ1-URJ64 Up Rear Hall Call Lockout Jewel Outputs
URO1-URO63 Hall Call - Up - Rear - Output
VIP1-VIP64 VIP Call - Combination I/O
VIPI VIP Indicator per Car
VIPJG VIP Indicator any Car
VIPR1-VIPR64 VIP Rear Call - Combination I/O
VPI1-VPI64 VIP Call - Input
VPO1-VPO64 VIP Call - Output
VPRI1-VPRI64 VIP Rear Call - Input
VPRO1-VPRO64 VIP Rear Call - Output
Designator Name
ACCI Audible Car Call Indicator
ADC Auxiliary Door Close
ADCL Auxiliary Door Close Limit (DCL)
AES Security-activate Hall Call Enable Subset
ALB Alternate Lobby Operation
ALTJ Alternate Floor Fire Service Jewel
AOV Security - Activate Car Call Overrides
ARDC Auxiliary Rear Door Close
ARDCL Auxiliary Rear Door Close Limit (DCL)
ARL Arrival Lantern
ARLR Arrival Lanterns - Rear
ATD Attendant Operation Door Speed
ATDR Attendant Operation Door Speed - Rear
BEEP Coded Car Call Entry Code Button Acknowledge
Designator (cont.)
Name
