INSTALLATION
Vertical Express Product Manual 1-21 88600 v.1.0
Installation Section Hoistway Wiring
Wireway and Conduit Layout
The following procedure is a suggested method of installation. See the job wiring
diagrams and the wiring diagrams on the following pages.
Required Wireways/Conduits
• Hall station and door interlock riser
• Machine room to junction box
• Hoistway access and final limits (if required)
• Controller cross-connects (group jobs only)
1. Mount the junction box to the guide rail at a point above the center point of car
travel and also above the entrance header. See the job layout for the proper
quadrant.
2. Run wireway/conduit from the power unit/controller in the machine room to
the junction box.
3. Install the hall station and the door interlock riser.
4. Run conduit and mount the hall signal fixture boxes.
5. Run conduit and mount boxes for the position indicators, the lanterns,
and the pit stop switch.
6. Run conduit for final limits as required.
To Next Page
