Vertical Express ICON 32 - L24;LHV;S24-1;S24-2 Cards

TROUBLESHOOTING
Vertical Express Product Manual 4-29 88500 v.1.0
Troubleshooting Section IOF Card (6300AHV001)
L24/LHV/S24-1/S24-2 Cards
LHV Card
6300PR
IN
OUT
K8 = Output #8
K7 = Output #7
K6 = Output #6
K5 = Output #5
K4 = Output #4
K3 = Output #3
K2 = Output #2
K1 = Output #1
S24-1 Card
6300VC1
CON11 &
CON12
CCIE Cross
Connections
CON2
OUT Port
CON1
IN Port
Pin 1 = P24
Pin 2 = I/O
Pin 3 = CCIE
Pin 4 = G24
CON3 -
CON10
24VDC POWER LED
L24 Card
6300LL4
CON1
CON3
(On-Card I/O Port)
CON2
Pin 1-8 = I/O 1-8
Pin 9 = G24
Pin 10 = P24
S24-2 Card
6300VL1
CON2
OUT Port
CON1
IN Port
24VDC
POWER
LED1
CON3
Pin 1 = I/O1
Pin 2 = I/O2
Pin 3 = I/O3
Pin 4 = I/O4
Pin 5 = I/O5
Pin 6 = I/O6
Pin 7 = I/O7
Pin 8 = I/O8
CON3B
Pin 1 = I/O5
Pin 2 = I/O6
Pin 3 = I/O7
Pin 4 = I/O8
Pin 5 = P24
CON3A
Pin 1 = I/O1
Pin 2 = I/O2
Pin 3 = I/O3
Pin 4 = I/O4
Pin 5 = P24
