ADJUSTMENT
Vertical Express Product Manual 2-3 88500 v.1.0
Adjustment Section Preliminary Adjustment
Preliminary Adjustment
Before beginning this section, the following must be completed:
1. The hoistway and traveling cable wiring.
2. The selector tape installation.
3. All components and sub-systems prepared for Automatic Operation.
4. The Valve Low Pressure and Bypass are set.
5. The leveling speed is set to 10-12 FPM.
Remove Temporary Operation
1. Turn OFF, Lockout, and Tagout the mainline disconnect.
2. Place the controller on Inspection Service.
3. Unplug CON4 on the IOF Card.
4. Remove the temporary runbug.
5. Remove the following temporary orange jumpers:
• Electronic Starters: 134 to MCC1 and MUTS to USS1.
• Across the Line Starters: 134 to USS1 and MCC1.
• Trades Access Panel: EPD2 to EPD2.
6. Connect the disconnect auxiliary contact between EPD1 and EPD2 terminals of
the Trades Access Panel. This action prevents alternate power from powering up
the controller with the disconnect in the OFF position.
7. Install plugs 9a, 19, 20, and 21 to corresponding connectors on the IOF Card.
8. Turn ON the mainline disconnect.
9. Confirm that the Watchdog (WD) LED on the CPUC is illuminated. See Figure 1
on page 2-4.
10. Confirm that the AC, P24, and P24G LEDs on the IOF Card are illuminated.
See Figure 1.
11. Confirm that the P24GS LED on Power Supply Module (PSM) P24GS is illumi-
nated. The P24GS fuse and PSM are located on DIN Rail above IOF Card.
12. Remove power.
13. Connect CON4 on the IOF Card.
14. Verify that the AC LED is still illuminated.
