Configure the CAN Nodes
CAN Node Address Assignment
1. Have some paper and pen/pencil ready to record node information for future use.
2. Access the UIT.
3. Navigate to BLOCK SELECT ADJUSTMENTS, and press ENTER.
4. Navigate to ADJUST MENU COMMANDS START UP, and press ENTER.
5. After DCN displays, press ENTER.
6. CN Node = 0 displays. Press UP or DOWN to select the proper CAN Node ID, and
press ENTER.
7. When Ping a Port? displays, press DOWN.
BLOCK SELECT
ADJUSTMENTS
ADJUST MENU
COMMANDS STARTUP
DCN
—
Display Sta
UP: Next DN: Prev
CN Node=0
UP:+ DN:
—
