Vertical Express ICON 32 - UIT Menu Tree

REFERENCE
Vertical Express Product Manual 5R - 3 88500 v.1.0
Reference Section UIT Menu Tree
UIT Menu Tree
Block Select
System Clock
Time hh:mm:ss
Date mm:dd:yy
ENTER
Set the Time?
UP = Yes DN = No
Set the Date?
UP = Yes DN = No
SUBMENU
Adjust Car/Group
Job Parameters (Jxx)
Code Blue (Cxx)
Doors (Dxx)
Emergency Power (Exx)
Fire Service (Fxx)
Fixtures (Xxx)
Homing & Shutdown (Hxx)
Incon Riser (Rxx)
Motion (Mxx)
Options 1 (Oxx)
Options 2 (Zxx)
Parking & Zoning (Lxx)
Position System (Pxx)
Security (Sxx)
SUBMENU
Commands
Group
GPN
SCA
SCAI
SUC
SDC
SRU
SRD
SSI
SHL
PIG
WRTG
Show Faults*
Clear Faults*
Reset Fault List
Front Car Call
Rear Car Call
UP Hall Call
DN Hall Call
Show Stable Leveling
Show I/O
*only displays if faults are present.
QUICK COMMANDS
Block Select
Adjustments
ENTER
SUBMENUS
Adjust Car/Group
Commands Common
Commands Upload
Commands Startup
Commands Group
Front Door
Rear Door
Block Select
Startup Wizard
ENTER
Start Wizard?
UP = Yes DN = No
Yes
No
Clear CN Config
Config CNs
Auto Hoistway Scan
Write to Flash
Save Job to USB
Block Select
Real Time Motion
Motion/Position
Status
Arbiter
ENTER
Velocity
SUBMENU
Commands
Common
CJR
DSL
FCP
GET
IOView
IRL
IRLR
RFL
RRF
SCC
SFL
SFLR
SRC
TMP
VER
WRT
TSR
TSRT
SUBMENU
Commands
Upload
UFWCNC
UFWCNH
UFWSPF
OSDM
UDLS
UDLR
SUBMENU
Commands
Startup
DCN
ELD
SCF
SPC
STU
TECC
TECCR
PRESS A BUTTON TO BEGIN
Notes:
• Use UP and DN to scroll
through blocks.
• Press ENTER to select.
• While in block menus,
use UP and DN to navigate.
• Use ESC to back out.
Pin: 1234144
(if incorrect, press reset)
Vertical
Express
Enter Pin #
1234
UP ENTERDN ESC
Block Select
Inspector’s Tests
FLT
RFL
TFR
SCCB
SCC2-SCCn
SCCT
(Set Car Call Bottom,
2,3,.... top in order)
ENTER
ENTER
ESC
Logoff UIT?
UP = Yes DN = No
Block Select
Show Fault Details*
FJR
WJR
Car Information
Desination Dispatch
Traffic
UFWSLF
OSDMI
JRT
PRT
STUA
