ICON32 I/O Chart Reference Section
©Vertical Express 5R - 8 Printed in USA April 2020
ICON32 I/O Chart
Port #
I/O Number
1 2 3 4 5 6 7 8
1 INCN INCNM INCNU INCND CDBM CDBM2 HDBM HDBM2
2 BYCST BYHA BYHAR BYHAB BYHAT BYCDB BYHDB BYDZ
3 IB IT IF IR CB CT CF CR
4 SAFSPM SAFCPU SAFCPM SAFE TSRCPU CDCF CDCR CST
5 MCC1 MCC2 UFS USS DFS DSS
6 MCC1M MCC2M UFSM USSM DFSM DSSM
7 PRSW OLTS OLTO
8 CHKTSR CHKDS TSRCPM NTSNPM
9DD
10 FSM FSX FSE FST FSSR STBC EPW EPNP
11 HATU HATUM HATD HATDM HABU HABUM HABD HABDM
12
13 FSBZ
14
15 LVU LVD DZ1 DZ2 LVUR LVDR DZ1R DZ2R
16 TSR1
17 INCTM INCTU INCTD INCTU2 INCTD2 INCT INHA INHAM
18
19 CCIE C1 C2
20
21 BUZ CLFS
22 DOB DCB FSC1 FSC2 FSRI FSCC
23 FSH1
24
25 HCIE U1 D2
26 D5 HLU1 HLD2
27 ISC
28
29
30
Ports 1-18 are IOF connections. Ports 19-30 are CNA node 0 (MODCTRL1).
