Vertical Express ICON 32 - Preliminary Setup for Automatic Operation; Hoistway Scan through the Startup Wizard

ADJUSTMENT
Vertical Express Product Manual 2-25 88500 v.1.0
Adjustment Section Preliminary Setup for Automatic Operation
Preliminary Setup for Automatic Operation
Before starting a hoistway setup, complete the following items:
1. Door operator adjustments. See the appropriate door operator component
manual for this job.
2. Mechanical setup.
3. Gate switch (CDCF, CDCR) and limit setting (DOL, DCL - DOL and DCL are always
required for Automatic Operation, regardless of door operator type).
4. Card configuration and setup.
5. Verify that the car stops on the directional magnets 1 - 1
1
/
2
" out of the terminal
landings.
• Before the car can run on Automatic Operation, the selector must scan (count)
the number of selector tape holes between floors.
• Any time a leveling magnet or directional limit magnet is moved, the hoistway
must be scanned again.
Hoistway Scan Through the Startup Wizard
The Startup Wizard sets up and configures all CAN nodes, performs a hoistway scan,
and executes job archive functions. Upon successful completion, the system will be
on Automatic Operation and ready for final valve adjustments. Previously, the CAN
nodes were configured. It is not necessary to duplicate those steps at this time,
unless there was incorrect CAN loading or bad nodes at the time of the original
configuration. It will not cause any harm to repeat the steps, and the following
procedure will complete the hoistway scan.
1. From Inspection Operation, place the car at, or above, the first landing.
2. Access the UIT.
3. Set the close floor adjustment. A close floor is defined as a floor with 4"- 16" of
travel to the floor above it.
a. If no close floor is present on this job, continue to step 4.
b. If system has a close floor, set P12=1.
Block Select Adjustments> Adjust Car/Group> Position System> P12.
4. Place all switches in the RUN or AUTOMATIC position (Pit Stop, Fireman's Stop,
Emergency Exit, SOS, Car Top Inspection Stop, etc.).
5. On the IOF Card, place the following switches in the Ready To Run on DOOR
DISCONNECT position:
• Car Door Bypass: OFF (DN)
• Hoistway Door Bypass: OFF (DN)
•Stop Switch: RUN (UP)
• Inspection Switch: NORMAL (UP)
• Door Disconnect Switch: Door Disconnect (UP)

