Diagnostics Section NP Fault Codes - NTSD Processor
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
NP Fault Codes - NTSD Processor
Code Description Possible Solutions
2801
The top terminal slowdown was activated – NP
detected NTST active while running Up Fast.
• Check the NTST magnet; P17 adjustment too low.
• Check the motor and valves.
2802
The bottom terminal slowdown was activated
– The NP detected NTST active while running
Up Fast.
• Check the NTSB magnet; P18 adjustment too low.
• Check the motor and valves.
2803
The top terminal stopping was activated – The
NP detected DL active and NTST active while
running Up.
• Check the NTST magnet; P17 adjustment too low.
• Check the motor and valves.
• Check the DL magnet.
2804
The bottom terminal stopping was activated –
The NP detected DL active and NTST active
while running Up.
• Check the NTSB magnet; P18 adjustment too low.
• Check the motor and valves.
• Check the DL magnet.
2805
The test outputs were not commanded within
three automatic runs.
• Reload the generic and job software.
• Replace the CPU Card.
2806 A FAST solenoid output test failure.
•RFL, RRF.
• Use a meter to check the UFSM input during an Auto Up run. If no VAC,
then use job diagrams to troubleshoot the output voltage supply.
2807 A safety string output test failure.
• Issue an FLT command.
• Check all wiring/connections to the IOF Card.
• Replace the IOF Card.
2808 TSMC data message Node A was not received.
• Check the car CAN channel.
•Check the TSMC.
2809
A corrupted TSMC Node A CAN message was
received.
• Check the Car CAN loading, the connections, and the cable routing.
• Replace the TSM Card.
2810
A corrupted TSMC Node B CAN message was
received.
• Check the Car CAN loading, the connections, and the cable routing.
• Replace the TSM Card.
2811
A corrupted main CPU CAN message was
received
• Noise on Car CAN channel or failing communication chip on CPU.
• Check the Car CAN loading, the connections, and the cable routing.
2812 A duplicate TSMC Node A was detected. —
2813 A car CAN channel bus Off failure.
• Check Car CAN channel loading, cable routing, shielding, & connec-
tions.
2814 A programming jumper was enabled. —
2815
A/C peak reference timeout - The NP lost A/C
power, so the A/C inputs cannot be sampled.
• Failed device on the IOF Card.
2816 A duplicate TSMC Node B was detected. —
2817
A TSMC data message Node B was not
received.
• Check the car CAN channel.
•Check the TSMC.
2818
A TSMC Node A and Node B data
mismatched.
—
2819 NP failed to configure the IOF FPGA. • Perform SPC again. If a persistent fault, replace the IOF Card.
2820 Bottom limit override and running fast. • Check DFS output and solenoid wiring.
2821 TSRCPM went false during fast valve test.
• Failing input/output on IOF Card - Try RFL, TFR, & cycle INSP to reset.
• Verify that the valve solenoid wiring matches the wiring diagrams.
2822
TSRCPM went false during safety string output
test.
• Failing input/output on IOF Card - Try RFL, TFR, & cycle INSP to reset.
• Verify that the valve solenoid wiring matches the wiring diagrams.
2823 Selector message timed out at power ON.
• Check power to the selector.
•
C
heck the Car CAN channel.
• Replace the TSMC.
2824 Selector Node A corrupted version message.
• Noise on Car CAN channel or failing communication chip on TSMC.
• Check Car CAN loading, connections, and cable routing.
2825 Selector Node B corrupted version message.
• Noise on Car CAN channel or failing communication chip on CPU.
• Check Car CAN loading, connections, and cable routing.
