Software Updates to Safety Node Devices over CAN
(continued)
3. Use the UIT to update the software of the Safety Processor.
a. Place JP2 on pins 1-2 beside the RSTSP.
b. Use the UIT to issue the following commands:
» UFWSPF Command: Adjustments > Commands Upload > UFWSPF.
» SPC Command: Adjustments > Commands Startup > SPC.
The UIT will display the upload progress and completion. When finished, the CPUC will
report SP Config Complete.
c. Place JP2 on pins 2-3.
d. Cycle power to the controller.
Table 2 - Software Update File Information
Configure the Safety Processor
1. Find the Safety Processor (SP) Programming Jumper JP2 (located on the IOF Card
next to RSTSP).
2. Place the SP Programming Jumper on pins 1 and 2.
3. From the UIT, press any button while Vertical Express is displayed, and enter the
pin number - 1234144. If the wrong pin number is entered, continue to press UP
until Vertical Express appears in the window, then enter the pin number again.
4. From the UIT, access Block Select Adjustments and press ENTER.
5. Press UP or DOWN to scroll to Commands > Startup, and press ENTER.
6. Press UP or DOWN to scroll to the SPC Command, and press ENTER.
• The UIT should display SP Config Complete.
• If the SP Programming Jumper is in the wrong position or the jumper shunt is bad,
the UIT will return SP Programming Jumper Not Installed. Correct the jumper,
and press ENTER again.
7. Place the SP Programming Jumper on pins 2 and 3.
8. Press RST on the CPUC. Once the controller recovers, repeat the steps to access the
Main Menu Screen.
At this point, the Safety Processor is configured and either the SP Good or the SP Bad LED
should be illuminated. The SP BAD LED will remain lit until the nodes have been taught
and configured.
Networking See Group CAN Channel Termination on page 4-9.
Device (via USB flash drive) Command File Name
Safety Processor UFWSPF SPH.vXrX
Normal Processor UFWNPF N/A
