Vertical Express ICON 32 - Traveling Cable Installation

INSTALLATION
Vertical Express Product Manual 1-27 88600 v.1.0
Installation Section Hoistway Wiring
Traveling Cable Installation
Hatch Mounting Assembly
Formed Rail
Mid Hatch Junction Box
2½" EMT to MR (optional)
2½" x 4" Wireway to MR (optional)
Kellums Grip
Traveling Cable to Car
JUNCTION BOX
MOUNTING
All traveling cable wires and hoistway wires must enter the controller
cabinet on the right side where the CPUC and IOF Cards are located.
CPUC & IOF
Cards
LOW
VOLTAGE
WIRING
