Diagnostics Section Adjustments
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
Adjustments
Adj Unit Range Definition
C10 sec. 0–900
Code Blue Door Hold Time - The time the doors will remain opened at the code blue desig-
nated floor. If, after this time, the Hospital Service switch has not been activated, the doors
will close and the car will return to normal operation.
Note: If the AST timer expires before CBH, the car will return to Automatic Operation.
C11-C25 cars 0–ncars
Code Blue Response Priority 1-15 - Use this adjustment to establish priorities for the cars
responding to Code Blue Operation.
C11 is the highest priority car followed by C12, etc.
A zero (0) for this adjustment turns OFF the Code Blue Operation for the car.
C26 — 0–1 Group Code Blue Operation - Set to 1 to enable.
D10 — 0–2
Limited Door Reversal Type
Values:
0 = Disabled
1 = Active with EE only
2 = Active with SE or EE
D11 — 0–2
Nudging Enable
Values:
0 = Disable
1 = Enable
2 = Enable with DOB override
The door open button causes the doors to fully reopen during nudging.
D12 — 0–8
Front Door Type
Values:
0 = No Door
1 = Electronic Door Operator using 6300PY_ Card
2 = Discrete Door Operator
3 = Freight Door (freight doors with auto open and auto close)
4 = Freight Manual (freight doors with no auto open, no auto close, no door times, and no
door watchdog protection timer)
5 = Freight Auto Open (freight doors with auto open only, no door watchdog protection
timer)
6 = Freight Auto Close (freight doors with auto close only, and with door
watchdog protection timer)
7 = Electronic Door Operator with CAN serial link. ICON32 with UDC (6300PA) Card or
LD-16 Door Operator
8 = Electronic Door Operator with RS-485 serial link
D13 — 0–8
Rear Door Type
Values:
0 = No Door
1 = Electronic Door Operator using 6300PY_ Card
2 = Discrete Door Operator
3 = Freight Door (freight doors with auto open and auto close)
4 = Freight Manual (freight doors with no auto open, no auto close, no door times, and no
door watchdog protection timer)
5 = Freight Auto Open (freight doors with auto open only, no door watchdog protection
timer)
6 = Freight Auto Close (freight doors with auto close only, and with door
watchdog protection timer)
7 = Electronic Door Operator with CAN serial link ICON32 with UDC (6300PA) Card or
LD-16 Door Operator
8 = Electronic Door Operator with RS-485 serial link
