SERVICE INFORMATION
Vertical Express Product Manual 5-37 88500 v.1.0
Service Information Section Software Management
Upload Software to CPU Cards
(continued)
12. Use Quick Commands, and issue car calls to verify Automatic Operation. Hall
calls do not function while on Door Disconnect Operation.
Block Select Real Time Motion > Quick Commands > Front Car Call/Rear Car
Call.
If the job configuration file was a manufacturing file and not a back up copy of an
adjusted job (from the UDLS Command), perform a new hoistway scan and adjust
for the job (Fire Service, HWA, EP, security, date/time, etc.). See the Adjustment sec-
tion of this manual.
13. Place the door disconnect switch in the OFF position.
14. Verify that the car and hall buttons function correctly.
15. Return the car to service.
Upload Software Troubleshooting
1. Verify the folder structure and the file location within the folder structure. See
USB Flash Drive Preparation on page 5-34.
2. Use a different USB flash drive (recommended device: part number 9811126).
3. Copy the software files to a different USB drive.
4. Format the USB flash drive. Create a new folder structure and copy needed
file(s) into the Update folder. See How to Format a USB Flash Drive on
page 5-32.
5. If the software fails to load again, replace the CPUC Card.
Software Updates to Safety Node Devices over CAN
1. Move the needed files into the "\tke\update" directory. See Table 2 on
page 5-38 for file identification.
See also: USB Flash Drive Preparation on page 5-34.
2. Place the controller on Inspection Operation.
To Next Page
