DIAGNOSTICS
Vertical Express Product Manual 3-21 88500 v.1.0
Diagnostics Section Inputs and Outputs
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
Inputs and Outputs
Designator
Name
ABP Security - A/B Program Switch
ABPJ Security - A/B Program Jewel
AFI At Floor Indicator
ALBA Alarm Button Activated
ALBI Alarm Button Activated Indicator
ALBL Alarm Bell (Fire Bell)
ARGF Active Roller Guide Fault
ARL1-ARL64 Arrival Lantern - Per Floor
ARLR1-ARLR64 Arrival Lantern Rear - Per Floor
ARNI Automatic Run Indicator
ATB Attendant Bypass Pushbutton
ATBI Attendant Bypass Indicator
ATDB Attendant Down Pushbutton
ATDC Attendant Door Close Speed
ATDI Attendant Down Indicator
ATT Attendant Service
ATTI Attendant Service Indicator
ATUB Attendant Up Pushbutton
ATUI Attendant Up Indicator
AUTOI Automatic Operation Indicator
AUTO2I Automatic and/or Security Operation Indicator
BUZ Buzzer - Floor Passing, Fire, and Nudging
BYSG Bypass Safety Gear Switch
C1-C64 Car Call - Combination I/O
CAPT Capture Operation
CAPTD Capture Operation Door Open
CAPTI Capture Operation Indicator
CAPTR Capture Operation Reset
CB Hoistway Door Closed Bottom
CB1-CB64 Code Blue Call - Combination I/O
CBAI Code Blue Active Indicator (Per Car)
CBELL Freight Door Call Bell
CBI1-CBI64 Code Blue Call - Input
CBJG Code Blue Indicator (Any Car)
CBO1-CBO64 Code Blue Call - Output
CBR1-CBR64 Code Blue Call - Rear - Combination I/O
CBRI1-CBRI64 Code Blue Call - Rear - Input
CBRO1-CBRO64 Code Blue Call - Rear - Output
CCEM Car Call Ind Enable Main
CCER Car Call Ind Enable Remote
CCIE Car Call Indicator Enable
CCM Control Cutout Main Station
CCPO Car Call Panel Open
CCR Control Cutout Remote Station
