Inputs and Outputs Diagnostics Section
©Vertical Express 3-22 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
CDBI Car Door Bypass Indicator
CDBM Car Door Bypass Monitor
CDBM2 Car Door Bypass - Monitor #2
CDCF Car Door Contact Front
CDCR Car Door Contact Rear
CF Hoistway Door Closed Front
CHKDS Check Doors and Stop Inputs
CI1-CI64 Car Call - Input
CL1-CL64 Car Call Lockout
CLD Car Lantern - Down
CLDR Car Lantern - Down Rear
CLFS Car Light/Fan Shutdown
CLI1-CLI64 Car Call Lockout Indicator
CLIR1-CLIR64 Car Call Lockout Indicator - Rear
CLO1-CLO64 Car Call Lockout Override
CLOR1-CLOR64 Car Call Lockout Override - Rear
CLR1-CLR64 Car Call Lockout - Rear
CLU Car Lantern - Up
CLUR Car Lantern - Up Rear
CO1-CO64 Car Call - Output
CR Hoistway Door Closed Rear
CR1-CR64 Car Call - Rear - Combination I/O
CRI1-CRI64 Car Call - Rear - Input
CRO1-CRO64 Car Call - Rear - Output
CST Car Stop Switch Monitor
CSTI Car Stop Switch Indicator
CT Hoistway Door Closed Top
D2-D64 Hall Call - Down - Combination I/O
DAD Direction Arrow - Down
DAU Direction Arrow - Up
DBEH Door Button Enable - Hall - Front
DBEHR Door Button Enable - Hall - Rear
DC Door Close
DCA Door Close Assist
DCAD Door Close Auto Disable - Front
DCADR Door Close Auto Disable - Rear
DCAE Door Close Auto Enable - Front
DCAER Door Close Auto Enable - Rear
DCAR Door Close Assist - Rear
DCB Door Close Button - Front
DCBR Door Close Button - Rear
DCL Door Close Limit
DCL6 Door Close Limit 6"
DCL6R Door Close Limit 6" - Rear
DCLR Door Close Limit - Rear
DCN Door Close Nudging
DCNR Door Close Nudging - Rear
DCR Door Close - Rear
Designator (cont.)
Name
To Next Page
