Vertical Express ICON 32 - IOF - Shunt Jumper Definitions;Settings; IOF - con Jumper Definitions;Settings; IOF - Push Buttons and Switches; IOF Fuses

IOF Card (6300AHV001) Troubleshooting Section
©Vertical Express 4-22 Printed in USA April 2020
IOF - Shunt Jumper Definitions/Settings
IOF - CON Jumper Definitions/Settings
IOF - Push Buttons and Switches
IOF Fuses
Name Purpose Position and Function
JP2 Configure Safety Processor
1-2: Programming Mode (PLD will open safety string).
2-3: Normal Operation (default)
JP3 Configure NTSD Processor
1-2: Programming Mode (PLD will open safety string).
2-3: Normal Operation (default)
Name Purpose Position and Function
CON47 Jump out SAFSP and/or SAFCPU
1-2: Jumps out SAFSP.
2-3: Jumps out SAFCPU.
CON46 Jump out NTSNP and/or TSRCPU
1-2: Jumps out NTSNP.
2-3: Jumps out TSRCPU.
CON9A Temporary Runbug Operation
1-2: Allows a complete safety string to the motor and valve when the runbug
has been removed from CON9.
Name Type Function
RSTSP Pushbutton Reset Safety Processor (SP).
RSTNP Pushbutton Reset NTSD Processor (NP).
CLR_FLT Pushbutton Clear Latched PLD Faults.
RUN Slide Run/Stop - Closes/Opens safety string.
HOISTWAY DOOR BYPASS Slide Requests Hoistway Door Bypass ON or OFF.
CAR DOOR BYPASS Slide Requests Car Door Bypass ON or OFF.
DOOR DISCONNECT Slide Requests Door Disconnect ON or OFF.
INCN Slide Requests Controller Inspection ON or OFF.
UP Pushbutton Requests movement in UP direction when INCN is ON and ENABLE is pressed.
ENABLE Pushbutton Enables UP/DOWN when INCN is ON.
DOWN Pushbutton Requests movement in DOWN direction when INCN is ON & ENABLE is pressed.
Fuse
Current
Rating
Function
F-EP 0.5A Feeds 120VAC to the EPEN relay coil.
F-PS 3.0A Feeds 120VAC to the controller power supplies.
F-AC1A 6.0A Feeds 120VAC to the car, including door operators and car DC power supply.
F-AC1B 0.5A Feeds 120VAC to the hoistway door interlock circuits.
F-AC1SC 3.0A Feeds 120VAC to the safety circuit, including Triac outputs.
F-P24 4.0A Feeds 24VDC lower voltage supplies and all 24V I/O in the controller.
F-P24G Variable
Feeds 24VDC to the hall risers wired to this controller.
Variable based on power requirements of risers connected to this controller.
F-P24GS N/A Not Used.
F-AC1 Variable
Feeds 120VAC from the T1 transformer X1 tap (CON16-1) to the source voltage for the EPEN relay
and contacts (CON18-1) to feed the system AC power (does not fuse UPS output).
F-P24L 1.0A Feeds 24VDC to the CPUC Card.
