SERVICE INFORMATION
Vertical Express Product Manual 5-35 88500 v.1.0
Service Information Section Software Management
USB Flash Drive Preparation
(continued)
6. Use Windows Explorer to access the job files placed in the "\tke\backup\" folder
and copy the required elevator's "jobxxnnnn.cfg" file to the "\tke\update" folder.
7. Use Windows Explorer to verify that the required software files are in the "/tke/
update" folder on the USB flash drive.
• Only one version of generic file is permitted in the folder at a time.
• If multiple job files are placed in the update folder, the STAT LED will continuously
flash every 100ms.
• If multiple generic files are present in the update folder at the time of an update,
the CPUC Card could become corrupted, requiring the Recover Utility to be used.
• The generic and configuration upload may be processed either individually
or simultaneously.
• The CPU uploads the configuration (_.cfg) file located in the "\tke\update"
folder. When the upload completes, the _.cfg file is deleted from the update
folder.
• The generic file remains in "\tke\update\" folder until manually deleted. This
is to facilitate updating generic files across a group of controllers using one
USB flash drive.
9. Remove the USB flash drive from the computer.
Backup the Job Software
1. Place the controller on Inspection Operation.
2. Insert the prepared USB flash drive into the CON6 USB port on the CPUC Card.
Transferring software between the CPUC and USB flash drives requires a
few minutes to complete. Resetting the card during this time could result in
corrupting the USB and the CPUC.
3. Enter the UDLS Command to copy the "jobxxnnnn.cfg" file and generic file from
the CPUC Card to the "\tke\backup\jobnumber" folder on the USB Flash Drive.
From UIT: Block Select Adjustments > Commands Upload > UDLS.
4. Once the backup is complete, remove the USB flash drive from the CPUC, and
return the car to operation.
