DIAGNOSTICS
Vertical Express Product Manual 3-19 88500 v.1.0
Diagnostics Section Commands
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
Commands
Name Definition
CJR This command clears the jack resync statistics.
DCN
DCN Display CN stats and channel/port assignments where:
Name = User friendly name of the node stored in the CPU
On = State of CAN communication (Online=1, Offline=0)
RxTot = Total number of frames received
ID = CN address per CN jumpers JP(7,6,5,4)
Ch = Physical channel (2=COP, 3=Hall)
SP = Number of shared ports between cars (Remote I/O Box)
TP = Number of total ports used by this CN
channel: Where 2=>Car, 3=>Hall
numPorts: 0-15 defines the number of ports used by this CN
port0 port1...port15: For each physical CN port used by this CN, list the associated port in I/O layout matching
the IMS I/O screen column.
DSL Display Stabilized Leveling Distance.
ELD
Elevator Designator Display - This command displays the ASCII designator for this car. ELD shows the designa-
tor displayed by Owner's IMS Group Dispatch Window. See also PIG.
FCP Floor Count Position Display Command - This command displays the encoder position count for each floor.
FJR Force Jack Resync - This command signals an immediate request for a jack resync operation.
GET
GET Parameters - This command retrieves the saved parameters from the EEPROM and moves them into RAM.
• The CPU only works with parameter values that are stored in its RAM memory.
• To display a parameter that caused an out of range error, type GET and press Enter.
• To eliminate a parameter error, enter a value in the appropriate range, save with the WRT Command, and
recall with the GET Command.
GPN Display Group Node - This command displays which node the car is communicating to (for group functions).
IOView IOView - This command displays the I/O names by bit location.
IRL
Inconspicuous Riser Lockouts - This command displays front landings that are locked out by the Inconspicuous
Riser Operation.
IRLR
Inconspicuous Riser Lockouts Rear - This command displays rear landings that are locked out by the Inconspic-
uous Riser Operation.
JRT Jack Resync Time - This command sets the time of day that a jack resync will occur.
OSDM Operating System Diagnostics - This command displays information to be sent to the log file.
PIG Group Floor Display - This command changes the position indicator display for the group.
PRT
Pressure Relief Test - This command allows the car to run to the stop ring to perform a Pressure Relief Test.
1. Place the car at the top landing.
2. Put the car on Inspection Operation.
3. Run the car onto the Top Directional Limit (DL).
4. Issue the PRT Command.
5. Run the car UP on Inspection Operation past the DL.
SCA
Scan Call Assignment Table - This command reviews the scan assignment table of all floors that effect group
(hall call) service.
SCC
Set Car Call - This command sets the nth landing car call. For rear calls, see SRC.
See also: SCCB, SCCT, SDC, SRC, SRD, SRU, and SUC.
SCF
Set Close Floor - This command allows viewing and editing of the close floor table. Note: This automatically
sets itself up during a hoistway scan. Close floor is 4–16 inches of travel between floors.
SCCB
Set Car Call Bottom - This command sets the bottom landing car call. To set, type SCCB and press Enter.
• If the bottom landing has a front opening, the front car call will be set.
• If the bottom landing does not have a front opening, the rear car call will be set.
See also: SCC, SCCT, SDC, SRC, SRD, SRU, SUC
