Adjustments Diagnostics Section
©Vertical Express 3-18 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
Z42 — 0,9,13
VIP Voice Message ID - This adjustment sets which message to activate with VIP Call.
0 = No message
9 = Code Blue message
13 = Custom message (requires custom chip).
Z43 — 0-1
Enable VIP Operation at Group Level.
Values:
0 = Disable
1 = Enable
Z44 0.1 sec. 0-100
Run Stall Time (Required by California) - This adjustment sets a timer that quickly detects a
stalled UP Run.
This timer is intended to prevent faults such as:
• A motor burn-out (in the event of a motor phase reversal).
• Running Up after rupture valve has activated (to prevent emptying tank).
Adj (cont.) Unit Range Definition (cont.)
