DIAGNOSTICS
Vertical Express Product Manual 3-17 88500 v.1.0
Diagnostics Section Adjustments
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
X21 — 0–4
Rear Lantern Type - This adjustment sets the type of lanterns used for rear openings.
Values:
0 = No Lanterns
1 = Car Lanterns only
2 = Hall Lanterns only
3 = Both Car and Hall Lanterns
4 = Arrival Lanterns
X22 — 0–2
Floor Passing Tone to Buzzer - This adjustment sets whether or not the buzzer in the car
station will be used for the floor passing tone.
Values:
0 = Buzzer in car station will not be used for floor passing tone.
1 = Buzzer in car station will be used for floor passing tone (only if FPT does not exist).
2 = Buzzer in car station will be used for floor passing tone.
X23 — 3–4
Number of Display Characters - This adjustment sets the number of display characters
available in the Digital PI. Note: For the Hall PI, see X28.
Values:
3 = 3-character display
4 = 4-character display
X24 0.1 sec. 1–20
GAL Tone Timer Adjustment - This adjustment sets the actual length of time that floor
passing tone signal will be active (to indicate the car is passing or arriving at a new floor).
X25 1/16 sec. 1–48 Flashing Timer - This adjustment sets the flashing rate of flashing jewels.
X28 — 3–4
Hall CAN Channel PI Number of Display Characters.
Note: For the Car PI, see X23.
Set to 3 = 3 character display
Set to 4 = 4 character display
Z12 — 0-2
Independent Service Call Latch - This adjustment allows Independent Service to latch car
calls while the doors are open; effected by O78 Adjustment.
Values:
0 = Disable independent service call latch.
1 = Enable independent service call latch, and flush all car calls on arrival.
2 = Enable independent service call latch, and leave further car calls latched on arrival.
Z15 — 0-3
Forcing Door Close - This adjustment is used for MAC DC door operators. DC will not be
active during a run. Possibly used for freight, if required.
Values:
0 = No MAC
1 = Front MAC Only
2 = Rear MAC Only
3 = Both Front and Rear MAC
Z26 — 0-255 —
Z33 sec. 0-3600
Car Fan Turn Off Timer - This adjustment sets the car idle time required before the cab fan
turns off.
Z34 sec. 0-3600
Car Light Turn Off Timer - This adjustment sets the car idle time required before the cab
lights turn off.
Z38 — 0-1
Hoistway Access Bottom Floor Door Selection.
Values:
0 = Front
1 = Rear
Note: Modifying this parameter requires SP & NP Configuration.
See also: O11, O21, O22, and Z39.
Z39 — 0-1
Hoistway Access Top Floor Door Selection.
Values:
0 = Front
1 = Rear
Note: Modifying this parameter requires SP & NP Configuration.
See also: O11, O21, O22, and Z38.
Adj (cont.) Unit Range Definition (cont.)
