This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
V26 — 0–2
VIP Calls Assigned by.
Values:
0 = Best Car
1 = Priority
2 = Preferred (Security or Kiosk)
X10 — 0–1
Audible Car Call Enable - This adjustment sets an audible signal to alert a handicapped
passenger that a car call has been accepted by the elevator.
Values:
0 = Disable
1 = Enable
X11 — 0–2
Arrow Type - This adjustment sets the direction and preference arrows.
Direction arrows indicate direction of actual car movement.
Preference arrows indicate direction in which car has a preference to run.
Values:
0 = Direction arrows
1 = Preference arrows
2 = Preference and direction arrows
X12 — 0–1
Car Lantern at Door Reversal Limit - This adjustment enables car lantern operation when
the door reaches the reversal limit switch.
Values:
0 = Disable
1 = Enable
X13 — 0–1
Car Lantern at Lobby - This adjustment enables car lantern operation when the car
reaches the lobby.
Values:
0 = Disable
1 = Enable
X14 0.1 sec. 1–48 Flasher Rate - This adjustment sets the flashing rate for the flashing jewels.
X15 — 0–4
Front Lantern Type - This adjustment sets the type of lanterns used for front openings.
Values:
0 = No Lanterns
1 = Car Lanterns only
2 = Hall Lanterns only
3 = Both Car and Hall Lanterns
4 = Arrival Lanterns
X16 0.1 sec. 0–40 Lantern Delay at Lobby - This adjustment sets the delay time of lantern activation at lobby.
X17 — 0–2
Lantern Fire Position - This adjustment sets when the lanterns activate during fire service.
Values:
0 = At slow-down
1 = At leveling zone
2 = At floor level
X18 0.1 sec. 0–20
Lantern Off Time - This adjustment sets the duty of the off time during on/off cycle of lan-
terns and gongs operation.
X19 0.1 sec. 0–20
Lantern On Time - This adjustment sets the duty of the on time during on/off cycle of lan-
terns and gongs operation.
X20 minutes 0–10
PI Timeout Time - This adjustment sets the time delay before the position indicators (PI)
will turn off (if allowed by other options that may be active).
Note: If this value is not set, PI Timeout will not be allowed.
