DIAGNOSTICS
Vertical Express Product Manual 3-15 88500 v.1.0
Diagnostics Section Adjustments
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
S15 sec. 0–255
Security Homing Delay - When Security Homing is enabled, this adjustment sets the delay
that must expire before the car is forced to the security return landing.
S16 0.1 sec. 0–255
Security Door Time - After security has homed the car, this adjustment sets the amount of
time the doors will stand open when the car has arrived at the security return landing.
S17 — 0–1
Security Exit Not Required - This adjustment allows all landings in a building to be secured,
including the security return landing.
Values:
0 = Security return landing can not be secured.
1 = Security return landing can be secured.
S18 — 0–1
Security Homing Enabled Between Calls - This adjustment returns the car to the security
return landing when it has no calls.
Values:
0 = Security homing is not enabled.
1 = Security homing is enabled.
S39 — 0–3
Car Call Lockout Override Registers Car Call - This adjustment activates a lockout override
input to register the associated car call.
Values:
0 = Lockout Override activation does not register the corresponding car call.
1 = Lockout Override activation registers the corresponding car call.
2 = While on Program A security, the Lockout Override activation registers the corre-
sponding car call.
3 = While on Program B security, Lockout Override activation registers the correspond-
ing car call.
S40 floor 0–nf Neonatal Landing A.
S41 floor 0–nf Neonatal Landing B.
S42 floor 1–nfloors Group Security Floor.
S43 — 0–11
Group Security Type - This adjustment (for group functions only) is a type of required
Tenant Security.
See also: S10 (CAR security type).
Values:
0 = (TYPE 0) No security required, or the group invokes security and the car homes and
shuts down if the return landing (S11) is set.
1 = (TYPE 1) Car call lockouts in the group.
2 = (TYPE 2) Car call lockouts in the group with override inputs in the car.
3 = (TYPE 3-1) Car call lockouts in the group with override inputs in the car.
4 = (TYPE 3-2) Security override output only.
5 = (TYPE 4) Group hall card readers is an invalid selection for the car.
6 = (TYPE 5) Security override output only.
7 = (TYPE 6) Car call lockouts at the car level.
8 = (TYPE 7) Car call lockouts at the car level (no group function).
9 = (TYPE 8) Contract configured security.
10 = (TYPE 9) Contract configured security.
11 = Ethernet security.
S50 floor 0–nf Neonatal Landing C.
S51 floor 0–nf Neonatal Landing D.
S52 — —
Emergency Dispatch to Secured Floors.
0 = Disable
1 = Enable
V10 sec. 0–900 VIP Call Door Standing Time.
V11-V25 — 0–16
VIP Call Priority - Establish priorities for car response to VIP calls.
Values:
0 = Disable service
V11 = Highest priority call
V25 = Lowest priority call
Adj (cont.) Unit Range Definition (cont.)
