Inputs and Outputs Diagnostics Section
©Vertical Express 3-30 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
BFSHD Shutdown
BFWAR Warning
BKLT Door Open Button Back light
CCREG Car Call Registered To Allow Freight Doors To Close (Chicago Fire Service)
CFSW Car Fan Operation Switch - OCFTO
CFTO Car Fan Turn Off
CHM Chimes, See OPIL
CLSW Car Fan Operation Switch
CLTO Car Light Turn Off
DCIR Door Closing Indicator - Rear
DDO Disable Doors And Leave Car Online For Pressurized Door Operation
DFSRM Multiple Power Units
DH2-DH64 Hall Call Down (High Voltage)
DHR2-DHR64 Hall Call Down Rear (High Voltage)
DISO Distress Operation
DISOB Lockdown Operation - Secondary Input
DISOI Distress Operation Indicator
DIX Discrete Front Down Halls Call
DIXR Discrete Rear Down Halls Call
DOLI Door Open Limit Indicator
DOLRI Door Open Limit Rear Indicator
DOX Discrete Front Down Halls Call
DOXR Discrete Front Down Halls Call
DSSRM Multiple Power Units
DZM Door Zone Monitor
DZMR Door Zone Monitor - Rear
EC Extra Riser of Car Calls
ECI Extra Riser of Car Calls
ECO Extra Riser of Car Calls
ECR Extra Riser of Car Calls
ECRI Extra Riser of Car Calls
ECRO Extra Riser of Car Calls
ED2-64 Handicap Hall Call Down
EDI2-64 Handicap Hall Call Down
EDO2-64 Handicap Hall Call Down
EDR2-64 Handicap Hall Call Down
EDRI2-64 Handicap Hall Call Down
EDRO2-64 Handicap Hall Call Down
ELO1-16 Emergency Power Lowering Complete
ELOJ1-16 Emergency Power Lowering Completed Jewel
EP1-EP16 Emergency Power Manual Select Car #
EPDI Emergency Power Disable
EPDO Emergency Power Disable Jewel
EPLOJ Emergency Power Lowering Jewel
EPSE Emergency Power Auto Selection Enabled
EPSLJ Emergency Power Selection Jewel
EU1-63 Handicap Hall Call Up
EUI1-63 Handicap Hall Call Up
Designator (cont.) Name
