DIAGNOSTICS
Vertical Express Product Manual 3-31 88500 v.1.0
Diagnostics Section Inputs and Outputs
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
EUO1-63 Handicap Hall Call Up
EUR1-63 Handicap Hall Call Up
EURI1-63 Handicap Hall Call Up
EURO1-63 Handicap Hall Call Up
FALDI Failure Indicator Output (Delayed)
FDFC Freight Door Force Close (Freight Doors TAC20, TAC60)
FDFCR Freight Door Force Close Rear
FPS1I Flooded Pit Indicator
FPS2 Flooded Pit
FPS2I Flooded Pit Indicator
FS1NI Fire Service Phase 1 Switch On Indicator
FS1RI Fire Service Phase 1 Switch Reset Indicator
FS2FI Fire Service Phase 2 Switch Off Indicator
FS2HI Fire Service Phase 2 Hold Indicator
FS2NI Fire Service Phase 2 Switch On Indicator
FSCDB In-car Secondary Fire Switch Door Bypass
FSCDM In-car Secondary Fire Switch Door Bypass Monitor
FSDB Fire Service Door Bypass
FSDOM Fire Service Fireman's Door Open Monitor
FSDOX Fire Phase 1 Alternate Floor Door Open
FSH6 Fire Service Phase 1 On (Tertiary Switch)
FSH7 Fire Service Phase 1 Off (Tertiary Switch)
FSH8 Fire Service Phase 1 On (Quaternary Switch)
FSH9 Fire Service Phase 1 Off (Quaternary Switch)
FSTFL Fire Service Top Final Limit
GL1M Gate And Lock Monitor #1
GL2M Gate And Lock Monitor #2
HCLA Security - Hall Call Lockout Activate
HCLD Hall / Car Lantern - Down - Front
HCLU Hall / Car Lantern - Up - Front
HCPR Hall Call Power Rear
HFJ Hall Call Power Failure Jewel
HFSJ Phase One Fire Service Jewel
HG Bit-packed Per-floor Combined Up & Down Hall Gongs
HGR Bit-packed Per-floor Combined Up & Down Hall Gongs
HLPWY Help is on the way
HOLD Next Up Hold Car
HPZ1 Hall Call Power Zone 1
HPZ1R Hall Call Power Zone 1 Rear
HPZ2 Hall Call Power Zone 2
HPZ2R Hall Call Power Zone 2 Rear
HPZ3 Hall Call Power Zone 3
HPZ3R Hall Call Power Zone 3 Rear
INDOP Independent Operation
JRSI Jack Resync Indicator
KPM Coded Car Call Entry Car Station In Keypad Mode
LWPI Load Weigher - Percent Indicator
MAINJ Main Floor Fire Service Jewel
Designator (cont.) Name
