Inputs and Outputs Diagnostics Section
©Vertical Express 3-32 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
MCFB Multiple Power Units
MGDI Sequential Starting Disable
MGDO Sequential Starting Disable
MOV Moving Indicator
MTO Material Transfer Operation
MTOI Material Transfer Operation Indicator
NOVIP Disable VIP Service with Key Switch
NXUA Next Up Active
NXUCA Next Up Car Active
NXUCD Next Up Car Dispatch
NXUCR Next Up Car Dispatch Rear
OLLD Oil Level Low Door
OFLO Emergency Power All Cars Failed Auto Selection
PDN Selector Moving Down Indication
PIC1-PIC64 Position Indicator - Discrete - Car
PUP Selector Moving Up Indication
REMOP Remote Operation
RSQ Rescue Recall Service (In Supervisor Panel)
RSQJ Rescue Recall Service (In Supervisor Panel) Indicator
RSQL Rescue Operation Switch - Left Car (In Control Panel)
RSQLJ Rescue Operation Switch - Left Car (In Control Panel) Indicator
RSQR Rescue Operation Switch - Right Car (In Control Panel)
RSQRJ Rescue Operation Switch - Right Car (In Control Panel) Indicator
RTC1-RTC16 Real Time Clock Output #1- Real Time Clock Output #16
RUNOK Run is OK
SCANDN Scan PI Down Reg CC When PI = Floor
SCANUP Scan PI Up Reg CC When PI = Floor
SEIOI Sound Buzzer if any of the Features are Activated and Seismic is not Deactivated
SEISJ Secondary Seismic Jewel
SOLAI Total Lockout Override Indicator
THLKJ Total Hall Call Lockout Jewel
UFSRM Multiple Power Units
UH1-UH64 Hall Call Down (High Voltage)
UHR1-UHR64 Hall Call Down Rear (High Voltage)
UIX Discrete Front Up Halls Calls
UIXR Discrete Rear Up Halls Calls
UOX Discrete Front Up Halls Calls
UOXR Discrete Rear Up Halls Calls
USSRM Multiple Power Units
XSEC Security Operation Override
ZONE1 Output Goes Active when Car is Below Specified Zone
ZONE2 Output Goes Active when Car is Between Upper and Lower Zones
Designator (cont.) Name
