Vertical Express ICON 32 - Page 16

Temporary Operation Installation Section
©Vertical Express 1-12 Printed in USA April 2020
Mechanical Starter Set Up with ESP200 Overloads
(continued)
Table 2 - Overload Specifications For ESP 200 Overload Applications
Motor
HP
Motor Voltage
(50 or 60 Hz)
NEC Motor NP
Rated Amps
Line or Phase
Wiring
Configuration
Overload
Current
Setting
Motor
HP
Motor Voltage
(50 or 60 Hz)
NEC Motor NP
Rated Amps
Line or Phase
Wiring
Configuration
Overload
Current
Setting
5
200V/208V 17.5 Line 25.0
30
200V/208V 92 Line 131.6
220V 15.9 Line 22.8 220V 84 Line 120.1
230V 15.2 Line 21.7 230V 80 Line 114.4
380V 9.2 Line 13.2 380V 48 Line 68.6
415V 8.4 Line 12.1 415V 44 Line 62.9
460V 7.6 Line 10.9 460V 40 Line 57.2
575V 6.1 Line 8.7 575V 32 Line 45.8
7.5
200V/208V 25 Line 35.8
40
200V/208V 120 Phase 99.1
220V 23 Line 32.9 220V 109 Phase 90.0
230V 22 Line 31.5 230V 104 Phase 85.9
380V 13 Line 18.6 380V 63 Line 90.1
415V 12 Line 17.2 415V 57 Line 81.5
460V 11 Line 15.7 460V 52 Line 74.4
575V 9 Line 12.9 575V 41 Line 58.6
10
200V/208V 32 Line 45.8
50
200V/208V 150 Phase 123.8
220V 29 Line 41.5 220V 136 Phase 112.3
230V 28 Line 40.0 230V 130 Phase 107.3
380V 17 Line 24.3 380V 79 Line 113.0
415V 15 Line 21.5 415V 72 Line 103.0
460V 14 Line 20.0 460V 65 Line 93.0
575V 11 Line 15.7 575V 52 Line 74.4
15
200V/208V 48 Line 68.6
60
200V/208V 177 Phase 146.0
220V 44 Line 62.9 220V 161 Phase 132.9
230V 42 Line 60.1 230V 154 Phase 127.1
380V 25 Line 35.8 380V 93 Line 133.0
415V 23 Line 32.9 415V 85 Line 121.6
460V 21 Line 30.0 460V 77 Line 110.1
575V 17 Line 24.3 575V 62 Line 88.7
20
200V/208V 62 Line 88.7
75
200V/208V 221 Phase 180.0
220V 56 Line 80.1 220V 201 Phase 166.0
230V 54 Line 77.2 230V 192 Phase 158.0
380V 33 Line 47.2 380V 116 Phase 95.8
415V 30 Line 42.9 415V 106 Phase 87.5
460V 27 Line 38.6 460V 96 Phase 79.3
575V 22 Line 31.5
25
200V/208V 78 Line 111.5
220V 71 Line 101.5
230V 68 Line 97.2
380V 41 Line 58.6
415V 37 Line 52.9
460V 34 Line 48.6
