Adjustments Diagnostics Section
©Vertical Express 3-12 Printed in USA April 2020
This manual shows only the parameters that have an operational relevance to the ICON32. The UIT may have
additional parameters available, which should not effect the controller operation.
O34 F/R 0–1
Lobby Recall Door - This adjustment sets the preferred door to open at the lobby recall
landing during lobby recall operation.
Values:
0 = Front
1 = Rear
O35 sec. 0–3600
Fan-Light Shutdown Timer - This adjustment sets the time that the fan and light turn off
(after all demand for service from the car has ended).
O36 floor 1–nf
Capture Return Landing.
Value:
0 = Stop car at the first available landing.
1 - nf = Specify which landing is the capture return landing.
O37 F/R 0–2
Capture Door To Open.
Values:
0 = Front
1 = Rear
2 = Both
O38 — 0–1
Capture Door Operation.
Values:
0 = The doors remain closed until opened with the CAPTD input.
1 = The doors open and stay open until deactivated.
O39 — 0–1
Capture Override Independent Service.
Values:
0 = No
1 = Yes
O40 — 0–1
Capture Override Car Stop Switch.
Values:
0 = No
1 = Yes
O41 — 0–1
Attendant Service Call Latch - This adjustment allows the attendant service to latch car
calls while the doors are open.
Values:
0 = Disable the latch
1 = Enable the latch
O42 — 0–1
This adjustment enables or disables the reverse car call cancel.
Values:
0 = Enable
1 = Disable
O43 —
0-65535
This adjustment enables or disables CE fixtures and VISTA monitoring.
Values:
0 = Off
9 = Enable CE fixture on the car CAN channel 2.
O44 # of starts 100-65535
Jack Resync Interval - This adjustment sets the number of motor starts necessary before
the launch of automatic jack resync operations.
See also: FJR, JRT, and O30
O45 — 0–1 Enable Sabbath Operation.
O55 F/R 0–1
Sabbath Operation Main Floor Opening - When the Sabbath Operation is initiated, this
adjustment sets the door opening at the recall floor (that will open after homing), to begin
dispatching to selected floors.
Values:
0 = Front doors
1 = Rear doors
Adj (cont.) Unit Range Definition (cont.)
