Industrial 1.6L Engine Mechanical 1-11
Crank Drive, Cylinder Block (Continued)
Engine 1.6 L Z 16 LE
Crankshaft Dimensions Main Bearing Journals 1 -5 Color Code
54.980 – 54.997 mm 2.1646 – 2.1652 in brownStandard size
54.980 – 54.997 mm 2.1646 – 2.1652 in green
54.730 – 54.747 mm 2.1547 – 2.1554 in brown/blueUndersize (0.25)
54.730 – 54.747 mm 2.1547 – 2.1554 in green/blue
54.482 – 54.495 mm 2.1450 – 2.1455 in brown/whiteUndersize (0.50)
54.482 – 54.495 mm 2.1450 – 2.1455 in green/white
Con-rod bearing journal
Standard size 42.971 – 42.987 mm 1.6918 – 1.6924 in -
Undersize (0.25) 42.721 – 42.737 mm 1.6819 – 1.6826 in blue
Undersize (0.50) 42.471 – 42.487 mm 1.6721 – 1.6727 in white
W ide m ain bearing journals
Standard size 26.000 – 26.052 mm 1.024 – 1.026 in -
Undersize (0.20) 26.200 – 26.252 mm 1.031 – 1.034 in -
Undersize (0.40) 26.400 – 26.452 mm 1.039 – 1.041 in -
