WAHLAP TECH PUSHING POINTS - Longitudinally-Moving Motor Components(PP-0503000-A)

6.7.3.1 Longitudinally-moving motor components (PP-0503000-A)
94
7
Hexagon flat-head screw M4*6（chrome plated）
2
6
Headless socket screw
M4*6（black coating）
3
5
Cross round-head combined
screw
M3*6（chrome plated）
4
4
Motor
TG-301DA-SR-65-CHA,24V 1
3 PP-0503A13
Horizentally-moving motor-gear
nylon
1
2 PP-0503A10
Longitudinally-moving motor
cover-plate
SPCC-0.8T 1
1 PP-0503A08
Longitudinally-moving motor
fixed-iron
SPCC-1.2T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
2
1
4
1
1
1
6
3
3
1
5
4
7
2
29
Note：Coating with screw glue
1.6.LS140012
1.6.LST40011#
1.6.LS830012
1.4.MD100031
