WAHLAP TECH PUSHING POINTS - Longitudinally-Moving Frame Components(PP-0503000-B)

6.7.3.2 Longitudinally-moving frame components (PP-0503000-B)
95
1
1
2
1
9
2
5
4
7
1
6
1
3
1
4
1
8
2
9
Hexagon nut with flange
M4（color coating）
2
8
Cross flat-head screw
M3*6（chrome plated）
2
7
Cross flat-head screw
M3*12（chrome plated）
1
6
Sensor
KI1300-AA07LF 1
5
Resin bearing
DR22C2 4
4 PP-0503A12
Left longitudinally-moving
optical-eye baffle
SPCC-0.8T 1
3 PP-0503A11
Longitudinally-moving
optical-eye baffle
SPCC-0.8T 1
2 PP-0503A07
Longitudinal drag-chain fixed-iron
SPCC-1.2T 1
1 PP-0503A06
Longitudinal slider fixed-iron
SPCC-1.2T 1
SN Name Qty
Drawing No.
Materials/specifications
Note
1.6.LM204013
1.6.LS230022
1.6.LS231022
5.4.WECHE0004
1.4.ZC030017
