6.3.1 Frame primary-components (PP-0101000)
68
Note：1. Apply the electrical
adhesive-tape
2. Tighten with the cable ties
1
1
2
1
3
1
22
4
22
4
7
1
9
1
23
6
8
1
24
2
11
4
25
16
12
4
26
4
13
4
14
2
27
2
15
2
16
4
28
8
17
2
28
4
18
1
28
2
19
2
20
2
29
1
5
1
21
2
28
4
29
1
31
20
6
1
23
8
22
11
10
1
30
1
4
1
22
2
32
2
33
1
33
1
34
1
35
2
32
Hexagon socket flat-head screw M4*8（chrome plated）
2
33
34
35
Isolating cylinder
Cross large flat head screw M3*12（chrome plated）
Anti surge device
5*7*5mm
KWM188Machine use 1.4.QT200010
1.6.LS231022
2
31
Cap nut
M4（chrome plated）
20
30
Hexagon socket flat-head screw M4*12（chrome plated）
1
29
Hexagon socket flat-head screw
M4*10（stainless steel）
2
28
Cross flat-head screw
M3*8（chrome plated）
18
27
hexagon nut with flange
M3（color coating）
2
26
Hexagonal nut
M16（color coating）
4
25
Cross round-head screw M6*20（chrome plated）
16
24
Cross flat-head screw
M4*10（chrome plated）
2
23
Hexagon socket flat-head screw
M4*20（chrome plated）
8
22
hexagon nut with flange
M4（color coating）
11
21
Ceiling lamp
3*1W yellow DC12V
2
20
Power socket
Card-type 3-hole 15A/AC125V
(American-standard)
2
19
5050 soft lamp-bar
DC12V RGB60 lamp L=2050mm
2
18
5050 hard lamp-bar
(aluminum case)
DC12V white 60 lamp L=500mm
1
17
5050 hard lamp-bar
(aluminum case)
DC12V white 60 lamp L=1000mm
2
16
5050 hard lamp-bar
(aluminum case)
DC12V white 60 lamp L=1100mm
4
15
Circular card-type button
Sanwa red SDP-103C-22RB
2
14
Sensor
KI1300-AA07LF 2
13
Plastic handle
white for wooden case
4
12
Anchor bolt
M16*Y100（color coating）
4
11
Activity castor
2.5'low gravity-center
4
10 PP-0101B02
Crossboard
MDF-20.0T 1
9 PP-0101B01
Rear-door plank
MDF-15.0T 1
8 PP-0101A08
Sealing- plate limit short-iron
SPCC-1.2T 1
7 PP-0101A07
Socket
SPCC-1.2T 1
6 PP-0101A06
Side-door
SPCC-1.2T 1
5 PP-0101A05
Spot-lamp fixing-iron
SPCC-1.2T 1
4 PP-0101A04
Power socket holder
SPCC-1.2T 1
3 PP-0101A03
Height front-adjustment orifice
SPCC-1.2T 1
2 PP-0101A02
Height rear-adjustment orifice
SPCC-1.2T 1
1 PP-0101A01
Frame weldment
1
SN Name Qty
Drawing No.
Materials/specifications
Note
1.4.JL302520
1.6.LSV99013
1.8.AA000020
5.4.WECHE0004
1.4.AJ500012#
1.4.ZM9E0073
1.4.ZM9E0072
1.4.ZM9E0085
1.4.ZM9E0509
1.5.XC203020
1.4.ZM9F0011
1.6.LM204013
1.6.LS142012
1.6.LS241012
1.6.LS862012
1.6.LM116013
1.6.LM203013
1.6.LS230032
1.6.LSF41015
1.6.LS141022
1.6.LM404012
1.6.LS140032
1.6.GL105010
