WAHLAP TECH PUSHING POINTS - Prize-Lane Components(PP-0104000)

71
6.3.4 Prize-lane components (PP-0104000)
1
1
2
4
6
4
7
4
3
1
5
1
4
1
9
2
8
3
9
2
10
6
10
Hexagon flat-head screw M4*8（chrome plated）
6
9
Hexagon nut with flange
M4（color coating）
4
8
Cross flat-head screw M4*8（chrome plated）
3
7
Cross flat-head screw M3*8（chrome plated）
4
6
Cross flat-head screw M4*10（chrome plated）
4
5 PP-0104D01
Prize outlet-door
PMMA-5.0T 1
4 PP-0104A03
Bottom left sealing-plate
SPCC-1.2T 1
3 PP-0104A02
Prize outlet-hinge
1
2 KC-0104C01
Prize door-mat
Rubber spring
4
1 PP-0104A01
Prize slideway
1
SN Name Qty
Drawing No.
Materials/specifications
Note
1.6.LS140032
1.6.LM204013
1.6.LS240022
1.6.LS230032
1.6.LS241012
